Measuring Machine Composite Fixture
Scan QR
×
Scan QR Code
https://mikrosize.com/product/measuring-machine-composite-fixture/

Technical Specifications

Name	Qty	Code
Elastic Pressing Plate	4	MS-100-S100
Short Steel Wire Pressing Plate	4	MS-100-S101
Long Steel Wire Pressing Plate	4	MS-100-S102
Short Pressing Plate Support Rod	8	MS-100-S103
Long Pressing Plate Support Rod	3	MS-100-S104
Support Rod with Diameter 6*5mm	3	MS-100-S0605
Support Rod with Diameter 6*10mm	6	MS-100-S0610
Support Rod with Diameter 6*25mm	6	MS-100-S0625
Support Rod with Diameter 9*5mm	3	MS-100-S0905
Support Rod with Diameter 9*10mm	6	MS-100-S0910
Support Rod with Diameter 9*20mm	6	MS-100-S0920
Support Rod with Diameter 9*25mm	6	MS-100-S0925
2Support Rod with Diameter 12×10mm	6	MS-100-S1210
Support Rod with Diameter 12×25mm	6	MS-100-S1225
Support Rod with Diameter 6×10mm (Flat Head)	4	MS-100-S0610F
Support Rod with Diameter 9×10mm (Flat Head)	4	MS-100-S0910F
Support Rod with Diameter 12×10mm (Flat Head)	4	MS-100-S1210F
Adjustable Height Support Rod with Diameter 9mm	2	MS-100-S1009
Spherical Support Rod with Diameter 6mm	2	MS-100-S106
Male Connector of Commutation Square	2	MS-100-F100
Elastic Bracket Locking Screw	2	MS-100-F101
Right Angle Positioning Block	1	MS-100-F102
Sliding Connection Plate	4	MS-100-F103
Commutation Square	1	MS-100-F104
Commutation Square Base	1	MS-100-F105
Elastic Bracket	1	MS-100-F106
M4-M8 Conversion Rod	4	MS-100-F107
Transparent Sliding Connection Plate	8	MS-100-F108
M3 Wrench	1	MS-100-F109
Firmware Tray	1	MS-100-F110
M4×10 Screw	20	MS-100-F111
Packing Box	1	MS-100-P100
