Analytical Balance
Scan QR
Technical Specifications
GL-C
|
Model |
GL1004C |
GL1104C |
GL1204C |
GL2004C |
GL2104C |
GL2204C |
|||||
|
Accuracy Degree |
(I) |
||||||||||
|
Weighing Range (g) |
0~100 |
0~110 |
0~120 |
0~200 |
0~210 |
0~220 |
|||||
|
Reading Accuracy (mg) |
0.1 |
||||||||||
|
Taring Range (g) |
0~100 |
0~110 |
0~120 |
0~200 |
0~210 |
0~220 |
|||||
|
Max |
+/-0.5e or +/-1e |
||||||||||
|
Repeatability Standard Deviation (g) |
0.0002 |
||||||||||
|
Calibration Mode |
Internal/External Calibration |
||||||||||
|
Calibration Weights (g) |
100 |
200 |
|||||||||
|
Pan size (Ф) |
80mm |
||||||||||
|
Dimension |
350*210*346mm |
||||||||||
|
Net Weight |
9kg |
||||||||||
|
Power |
DC12V/1A |
||||||||||
GL-B
|
Model |
GL1004B |
GL1104B |
GL1204B |
GL2004B |
GL2104B |
GL2204B |
|||||
|
Accuracy Degree |
(I) |
||||||||||
|
Weighing Range (g) |
0~100 |
0~110 |
0~120 |
0~200 |
0~210 |
0~220 |
|||||
|
Reading Accuracy (mg) |
0.1 |
||||||||||
|
Taring Range (g) |
0~100 |
0~110 |
0~120 |
0~200 |
0~210 |
0~220 |
|||||
|
Max |
+/-0.5e or +/-1e |
||||||||||
|
Repeatability Standard Deviation (g) |
0.0002 |
||||||||||
|
Calibration Mode |
External Calibration |
||||||||||
|
Calibration Weights (g) |
100 |
200 |
|||||||||
|
Pan size (Ф) |
80mm |
||||||||||
|
Dimension |
350*210*346mm |
||||||||||
|
Net Weight |
9kg |
||||||||||
|
Power |
DC12V/1A |
||||||||||
|
Model |
JA1003C |
JA1203C |
JA2003C |
JA2603C |
JA3003C |
JA5003C |
|
|
Accuracy Degree |
(II) |
||||||
|
Weighing Range |
0~100g |
0~120g |
0~200g |
0~260g |
0~300g |
0~500g |
|
|
Reading Accuracy (mg) |
1 |
||||||
|
Taring Range |
0~100g |
0~120g |
0~200g |
0~260g |
0~300g |
0~500g |
|
|
Max |
+/-0.5e or +/-1e |
||||||
|
Repeatability Standard Deviation (g) |
0.0002 |
||||||
|
Calibration Mode |
Internal/External Calibration |
||||||
|
Calibration Weights (g) |
100 |
200 |
300 |
500 |
|||
|
Pan size (Ф) |
80mm |
130mm |
|||||
|
Dimension |
350*210*346mm |
||||||
|
Net Weight |
9kg |
||||||
|
Power |
DC12V/1A |
||||||
|
Model |
JA1003N |
JA1203N |
JA2003N |
JA2603N |
JA3003N |
JA5003N |
|
|
Accuracy Degree |
(II) |
||||||
|
Weighing Range |
0~100g |
0~120g |
0~200g |
0~260g |
0~300g |
0~500g |
|
|
Reading Accuracy (mg) |
1 |
||||||
|
Taring Range |
0~100g |
0~120g |
0~200g |
0~260g |
0~300g |
0~500g |
|
|
Max |
+/-0.5e or +/-1e |
||||||
|
Repeatability Standard Deviation (g) |
0.0002 |
||||||
|
Calibration Mode |
External Calibration |
||||||
|
Calibration Weights (g) |
100 |
200 |
300 |
500 |
|||
|
Pan size (Ф) |
80mm |
130mm |
|||||
|
Dimension |
350*210*346mm |
||||||
|
Net Weight |
9kg |
||||||
|
Power |
DC12V/1A |
||||||
