MBrin-62.5 Brinell Hardness Tester

Scan QR

×

Scan QR Code

https://mikrosize.com/product/mbrin-62-5-brinell-hardness-tester/

Product Feature：

• The MBrin-62.5Digital Touch Screen Low-Load Brinell Hardness Tester is an opto-mechatronic high-tech product equipped with a brand-new high-resolution color touch screen for intuitive display and easy operation.
• The screen features adjustable backlight and energy-saving mode.
• The touch screen directly displays information such as measurement scale, indentation diameter, hardness value and conversion scale.
• Hardness test results are stored in real time, supporting data classification, selective deletion and printout, with automatic calculation of maximum, minimum and average values.
• Brinell hardness measurement with low test forces
• Digital display micrometer eyepiece for convenient measurement
• Automatic turret with dual objectives, allowing quick switching to measure indentations of different sizes
• The instrument offers 8 levels of test force and 9 Brinell test scales for optional selection.
• It is equipped with 5× and 10× objectives, both available for measurement; automatic switching between objectives and indenters is supported.
• The tester allows presetting of test force dwell time and adjustment of measuring light source brightness. Adopting a dual-light-source design with halogen lamp and LED, it adapts to various specimen surfaces and ensures a clear field of view.
• Itis equipped with an RS232 interface for data output to a computer. A CCD automatic image measurement system is optional.

Product Application：

• It is suitable for hardness testing of materials such as cast iron, steel, non-ferrous metals and soft alloys, as well as certain non-metallic materials including hard plastics and bakelite.
